We are specialized in Medium Duty PVC Caster Wheel, which integrates research and development, design, production, quality control and marketing.
PVC
Galvanized iron
3Inch/4Inch/5Inch
32mm
85kg/100kg/115kg
105mm/129mm/155mm
12.5mm
Swivel type
Model | Wheel Material
| Wheel Diameter (mm) | Wheel Width (mm) | Loading Height (mm) | Bolt Hole Diameter (mm) | Loading Capacity (kg) |
GIDM08-3IN-BU | PVC | 75 | 32 | 105 | 12.5 | 85 |
GIDM08-4IN-BU | PVC | 100 | 32 | 129 | 12.5 | 100 |
GIDM08-5IN-BU | PVC | 125 | 32 | 155 | 12.5 | 115 |
Additional information
√ Wheel Color: Black, customized.
√ Metal Fork Color: Silver, customized.
√ Bolt Hole Diameter: Regular, customized.
√ Wheel Material: PVC, customized.
√ Metal Fork Material: Galvanized iron, customized.
