We are specialized in Medium Duty Iron Core PU Caster Wheel, which integrates research and development, design, production, quality control and marketing.
Iron Core PU
Galvanized iron
3Inch/4Inch/5Inch
32mm
100kg/125kg/150kg
105mm/129mm/155mm
94x64mm
74x45mm
8.5mm
Swivel type
| Model |
Wheel Material
|
Wheel Diameter (mm) |
Wheel Width (mm) |
Loading Height (mm) |
Top Plate Size (mm) |
Hole Spacing Size (mm) |
Mounting Hole Size (mm) |
Loading Capacity (kg) |
GIDM09-3IN- FU | Iron Core PU | 75 | 32 | 105 | 94*64 | 74*45 | 8.5 | 100 |
GIDM09-4IN- FU | Iron Core PU | 100 | 32 | 129 | 94*64 | 74*45 | 8.5 | 125 |
GIDM09-5IN- FU | Iron Core PU | 125 | 32 | 155 | 94*64 | 74*45 | 8.5 | 150 |
Additional information
√ Wheel Color: Red, customized.
√ Metal Fork Color: Silver, customized.
√ Plate Size: Regular, customized.
√ Wheel Material: Iron Core PU, customized.
√ Metal Fork Material: Galvanized iron, customized.
