We are specialized in Light Duty PVC Caster Wheel, which integrates research and development, design, production, quality control and marketing.
PVC
Galvanized iron
2Inch/2.5Inch/3Inch/4Inch/5Inch
17mm/21mm/21mm/27mm/27mm
35kg/40kg/45kg/65kg/85kg
69mm/90mm/105mm/129mm/155mm
50x50mm/65x65mm/76x76mm
35x35mm/45x45mm/55x55mm
6.5mm/6.5mm/6.5mm/8.5mm/8.5mm
Swivel type with Brake
| Model |
Wheel Material
|
Wheel Diameter (mm) |
Wheel Width (mm) |
Loading Height (mm) |
Top Plate Size (mm) |
Hole Spacing Size (mm) |
Mounting Hole Size (mm) |
Loading Capacity (kg) |
GIDL10-2IN -FDB | PVC | 50 | 17 | 69 | 50*50 | 35*35 | 6.5 | 35 |
GIDL10-2.5IN -FDB | PVC | 65 | 21 | 90 | 65*65 | 45*45 | 6.5 | 40 |
GIDL10-3IN -FDB | PVC | 75 | 21 | 105 | 65*65 | 45*45 | 6.5 | 45 |
GIDL10-4IN -FDB | PVC | 100 | 27 | 129 | 76*76 | 55*55 | 8.5 | 65 |
GIDL10-5IN -FDB | PVC | 125 | 27 | 155 | 76*76 | 55*55 | 8.5 | 85 |
Additional information
√ Wheel Color: Blue.
√ Metal Fork Color: Silver, customized.
√ Plate Size: Regular, customized.
√ Wheel Material: PVC, customized.
√ Metal Fork Material: Galvanized iron, customized.
